Ø 59
R: Mechanical Limit + Build in Receiver
Full Control with Advanced Technology!
Thanks to its built-in receiver technology, it offers remote control ease and provides superior performance for large, heavy shading systems. With its high torque power and durable structure, it offers a long-lasting and reliable solution even in industrial use. With its quiet and efficient working principle, it maximizes the security and comfort your business needs to the highest level.
Technical Specifications
| MOTOR TYPE | OPERATING VOLTAGE | RATED TORQUE | RATED SPEED | TUBE DIAMETER | RATED POWER INPUT | RATED CURRENT | OPERATING TIME | MAX. NUMBER OF TURNS | WEIGHT |
|---|---|---|---|---|---|---|---|---|---|
| 59R-140/7 | 230V/50 Hz | 140 N.m | 7 rpm | 59 mm | 350W | 1.34 A | 4 min. | 24 Turns | 5.65 kg |



User Manual
